ProCharger 500 HP Air-to-Air Intercooler 3" | AIFP1A-004
ProCharger Universal Air-to-Air Intercooler — 500 HP
Genuine ProCharger sheet-metal intercooler for custom centrifugal-supercharger charge-pipe fabrication. This core uses opposite sides 3" inlet/outlet connections and is rated by ProCharger for combinations up to approximately 500 HP.
Specifications
- Part number: AIFP1A-004
- Type: Air-to-Air, sheet-metal end tanks
- Inlet/outlet orientation: Opposite Sides
- Inlet/outlet diameter: 3"
- Maximum recommended power: 500 HP
- Approximate core dimensions: 18 × 12.5 × 3.5 inches
Fitment: Universal fabrication component. Add approximately 2 inches on each side carrying an inlet or outlet when checking available space. Tubing, couplers, clamps, brackets, bypass hardware and installation are not included.
